F3SG-SR
User’s Manual
Chapter2 Floating Blanking
System Operation and Functions
E
 Detection capability
Detection capability for F3SG-SR differs based on the number of floating beams as shown below.
 LED indicator status
When Floating Blanking is being enabled, the Blanking indicator turns on.
 Limitation for combination with other functions
You can use this function in combination with the Muting, Fixed Blanking, and Warning Zone functions
at the same time with the SD Manager 3. Settings for respective zone have limitations.
Refer to 2-1. Combination of Functions for more information on the use in conjunction with other functions.
Model
Number of floating beams
configured
Detection capability
Number of blocked beams to
turn safety outputs OFF
F3SG-SR-14
- 14 mm 1 beam
1 beam 24 mm 2 beams
2 beams 34 mm 3 beams
3 beams 44 mm 4 beams
4 beams 54 mm 5 beams
n beams 14+(10×n) mm (n+1) beams
F3SG-SR-25
- 25 mm 1 beam
1 beam 45 mm 2 beams
2 beams 65 mm 3 beams
3 beams 85 mm 4 beams
4 beams 105 mm 5 beams
n beams 25+(20×n) mm (n+1) beams
F3SG-SR-45
- 45 mm 1 beam
1 beam 85 mm 2 beams
2 beams 125 mm 3 beams
3 beams 165 mm 4 beams
4 beams 205 mm 5 beams
n beams 45+(40×n) mm (n+1) beams
F3SG-SR-85
- 85 mm 1 beam
1 beam 165 mm 2 beams
2 beams 245 mm 3 beams
3 beams 325 mm 4 beams
4 beams 405 mm 5 beams
n beams 85+(80×n) mm (n+1) beams
