Omron F3SG-SRB Series User Manual

106
Chapter2 Warning Zone
F3SG-SR
User’s Manual
System Operation and Functions
When a warning zone is configured, you must attach Warning Zone Label (included) that indicate a
border between normal detection zone and warning zone.
The CFG indicator of the F3SG-SR is illuminated when the Warning Zone is enabled.
Refer to 2-1. Combination of Functions for more information on the use in conjunction with other functions.
Warning Zone
Upper 6 beams
Warning Zone
Lower 4 beams
LowerUpper
Fig. 4
LowerUpper
LowerUpper
All beams are
warning zone
A
ll beams are
detection zone
Fig. 7
Fig. 8
LowerUpper
Fig. 5
UpperLower
Warning Zone
All beams are
warning zone
Upper
Lower
Fig. 6
Detection Zone
Detection Zone
Detection Zone
Detection Zone
Primary sensor
(Channel 1)
Secondary sensor
(Channel 2)
Warning
Zone
<F3SG-RA front surface>
Warning Zone Label
* Attach the Warning Zone Label
to the side surface of the F3SG-RA.
<F3SG-RA side surface>
Detection
Zone
Normal
beam
Warning
beam
