244
Chapter4 Basic Operation of SD Manager 3 Mobile APP
F3SG-SR
User’s Manual
Setting with SD Manager 3
Sensor I/O Information
Sensor I/O information can be displayed by the following method.
1. Tap the following icons on the main screen.
2.
On the status monitoring screen, tap [Sensor I/O information] from the [Status Switching] button.
3.
The screen below is displayed.
No. Function name Description
1 Sensor I/O information display Displays the I/O information of the sensor being monitored.
2 Function switching The icon of the function which is being monitored is highlighted. Tapping the icon of the
other function switches to the display of the corresponding function.
To Next Page
