23
F3SG-SR
User’s Manual
Chapter1
List of Models
Overview and Specifications
E
 Arm/leg protection (Detection capability: 45-mm dia.)
Note 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
Note 2. The response times are values when Scan Code is set at Code B. The response times for Code A are 1 ms shorter than
these values.
Refer to 2-3. Mutual Interference Prevention for more information.
 Body protection (Detection capability: 85-mm dia.)
Note 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
Note 2. The response times are values when Scan Code is set at Code B. The response times for Code A are 1 ms shorter than
these values.
Refer to 2-3. Mutual Interference Prevention for more information.
Model
Number
of beams
Protective
height
[mm]
Response time
(Optical synchronization)
[ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0240-45 6 240 8 40 140 10 50
F3SG-4SR0400-45 10 400 8 40 140 10 50
F3SG-4SR0560-45 14 560 8 40 140 10 50
F3SG-4SR0720-45 18 720 8 40 140 10 50
F3SG-4SR0880-45 22 880 8 40 140 10 50
F3SG-4SR1200-45 30 1200 8 40 140 10 50
F3SG-4SR1520-45 38 1520 8 40 140 10 50
Model
Number
of beams
Protective
height
[mm]
Response time
(Optical synchronization)
[ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0280-85 4 280 8 40 140 10 50
F3SG-4SR0440-85 6 440 8 40 140 10 50
F3SG-4SR0600-85 8 600 8 40 140 10 50
F3SG-4SR0760-85 10 760 8 40 140 10 50
F3SG-4SR0920-85 12 920 8 40 140 10 50
