F3SG-SR
User’s Manual
Chapter1 List of Models
Overview and Specifications
E
 Arm/leg protection (Detection capability: 45-mm dia.)
Note 1. The net weight is the weight of an emitter and a receiver.
Note 2. The gross weight is the weight of an emitter, a receiver, included accessories and a package.
 Body protection (Detection capability: 85-mm dia.)
Note 1. The net weight is the weight of an emitter and a receiver.
Note 2. The gross weight is the weight of an emitter, a receiver, included accessories and a package.
Model
Number of
beams
Protective
height [mm]
Current consumption [mA] Weight [kg]
Emitter Receiver Net Gross
F3SG-4SRA0240-45 6 240 60 107 0.6 1.4
F3SG-SRB0240-45 6 240 52 95 0.6 1.4
F3SG-4SRA0400-45 10 400 71 116 1 1.9
F3SG-SRB0400-45 10 400 56 95 1 1.9
F3SG-4SRA0560-45 14 560 82 124 1.4 2.3
F3SG-SRB0560-45 14 560 60 96 1.4 2.3
F3SG-4SRA0720-45 18 720 93 133 1.8 2.8
F3SG-SRB0720-45 18 720 64 96 1.8 2.8
F3SG-4SRA0880-45 22 880 104 141 2.2 3.2
F3SG-SRB0880-45 22 880 68 97 2.2 3.2
F3SG-4SRA1200-45 30 1200 125 158 3.1 4.2
F3SG-SRB1200-45 30 1200 75 98 3.1 4.2
F3SG-4SRA1520-45 38 1520 147 175 3.9 5.3
F3SG-SRB1520-45 38 1520 83 99 3.9 5.3
Model
Number of
beams
Protective
height [mm]
Current consumption [mA] Weight [kg]
Emitter Receiver Net Gross
F3SG-4SRA0280-85 4 280 63 111 0.7 1.5
F3SG-SRB0280-85 4 280 50 95 0.7 1.5
F3SG-4SRA0440-85 6 440 72 120 1.1 2
F3SG-SRB0440-85 6 440 52 95 1.1 2
F3SG-4SRA0600-85 8 600 81 128 1.5 2.5
F3SG-SRB0600-85 8 600 54 96 1.5 2.5
F3SG-4SRA0760-85 10 760 91 136 1.9 2.9
F3SG-SRB0760-85 10 760 56 96 1.9 2.9
F3SG-4SRA0920-85 12 920 100 145 2.3 3.4
F3SG-SRB0920-85 12 920 58 96 2.3 3.4
