Panasonic FP Series User Manual

Conversion instructions
155
Part II IEC Instructions
STRING_TO_INT
STRING (decimal format) to INTEGER
Thereby the attached string is first converted to a value of the data type STRING[32]. Finally this is
converted to a value of the data type INT via a sub-programm of approx. 270 steps that is also
used in the functions STRING_TO_INT, STRING_TO_WORD, STRING_TO_DINT and
STRING_TO_DWORD.
To add an enable input and enable output to the instruction, select [With EN/ENO] from the
"Instructions" pane (LD, FBD or IL editor). To reuse an instruction select "Recently used" from the
context menu or press <Ctrl>+<Shift>+<v> in the programming window.
Permissible format:
'[Space][Sign][Decimal numbers][Space]' e.g. ' 123456 '
Permissible characters:
Space All characters except for "+“ (plus), "-" (minus) and all decimal numbers
Sign "+“ (plus), "-" (minus)
Decimal
numbers
Decimal numbers "0 - 9“
The analysis ends with the first non-decimal number.
PLC types
Availability of STRING_TO_INT (see page 1331)
Data type Comment
STRING input variable
INT output variable
Description
This function converts a STRING in decimal format to a value of the data type INT.
Example
Data types
