Panasonic FP Series User Manual

Data transfer via communication ports
717
Part III FP Instructions
22.2.1.3 Setting in RUN Mode with SYS instructions (FP-Sigma, FP-X)
Please refer to the description of SYS1, communication condition setting (see page 980) and to the description
of SYS2 (see page 993).
22.2.1.4 Changing the communication mode in RUN mode

NOTE
When the power is turned on, the communication mode selected in the system registers is set.
It is not possible to change to the Modbus RTU mode using F159_MTRN.
The communication mode of the CPU's communication ports can be changed during RUN mode.
You can toggle between program controlled mode and MEWTOCOL-COM mode by executing
F159_MTRN and setting the variable n_Number (the number of bytes to be sent) to 16#8000.
POU
Header and
LD Body
The communication mode flag turns on when program controlled mode is active. It turns off when
MEWTOCOL-COM mode is active. The flag can be evalutated using the system variable
sys_bIsComPort1ProgramControlled, sys_bIsComPort2ProgramControlled, or
sys_bIsToolPortProgramControlled.
ST Body
