Appendix Programming Information
1288
No. Name Default Values
414 COM port 2 - sending end code/reception done condition CR CR/CR+LF/ETX/Non
e
418 COM port 2 - receive buffer starting address 2048 0–32762
419 COM port 2 - receive buffer capacity 0 0–2048
412 COM port 2 - modem connection Disable Disable/Enable
1)
For PLC Link, the communication format and baud rate settings are fixed:
Data length: 8 bits
Parity: Odd
Stop bit: 1 bit
End code: CR
Start code: No STX
Other system register settings will be ignored.
2)
FPG-COM4: For RS485 connections (COM port 1), the baud rate must be set in the system registers and
with
the DIP switch.
40.8.4 System registers for FP0R
Memory size
No. Name Default Values
0 Sequence program area size
12/16/32 kwords
1)
Fixed
1)
Depending on PLC type (12k, 16k, or 32k type)
Hold on/off
1)
No
.
Name Default Values
5 Counter start address 1008 0–1024
6 Timer/Counter hold area start address 1008
Fixed/0–1024
3)
7 Internal relay hold area start address (in word units) 248
Fixed/0–256
3)
8 Data register hold area start address 12000/
32450
2)
Fixed/0–32763
3)
10 Link relay hold area start address for PLC Link 0 (in word units) 64
Fixed/0–64
3)
11 Link relay hold area start address for PLC Link 1 (in word units) 128
Fixed/64–128
3)
12 Link register hold area start address for PLC Link 0 128
Fixed/0–128
3)
13 Link register hold area start address for PLC Link 1 256
Fixed/128–256
3)
14 Step ladder hold/non-hold Non-hold Fixed or
Hold/Non-hold3)
1)
FP0R-T32: If the battery is empty and additional hold areas have been defined, the hold/non-hold operation
becomes unstable. The data value will become indefinite. It is cleared to 0 the next time the power is turned on.
2)
Depending on PLC type (16k/32k type)
3)
Depending on PLC type (Fixed for C10, C14, C16, C32, variable for T32, F32)
To Next Page
