Appendix Programming Information
1289
Act on Error
No. Name Default Values
4 DF-, P-function leading/falling edge detection Holds result Holds result/disregards result
20 Duplicate output Enable Fixed
23 I/O verification error Stop Stop/Continue
26 Operation error Stop Stop/Continue
Time-Out
No. Name Default Values
30 Watchdog timer time-out 699.1ms Fixed
31 Multi-frame communication time 6500.0ms 10.0–81900.0ms
32 Timeout value for the communication
functions based on F145, F146, F152,
F153
10000.0ms 10.0–81900.0ms
34 Constant scan time 0.0ms 0.0–600.0ms
0.0: Normal scan (non-constant)
PLC Link
No. Name Default Values
46 PLC Link 0 and 1 allocation setting Normal Normal/Reverse
47 PLC link 0 - Highest station number in network 16 1–16
40 PLC link 0 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
42 PLC link 0 - Link relays - Send area - Start sending from this word
address
0 0–63
43 PLC link 0 - Link relays - Send area - Number of words to send 0 0–64 words
41 PLC link 0 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
44 PLC link 0 - Link registers - Send area - Start sending from this
word address
0 0–127
45 PLC link 0 - Link registers - Send area - Number of words to send 0 0–127 words
57 PLC link 1 - Highest station number in network 16 1–16
50 PLC link 1 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
52 PLC link 1 - Link relays - Send area - Start sending from this word
address
64 64–127
53 PLC link 1 - Link relays - Send area - Number of words to send 0 0–64 words
51 PLC link 1 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
54 PLC link 1 - Link registers - Send area - Start sending from this
word address
128 128–255
55 PLC link 1 - Link registers - Send area - Number of words to send 0 0–127 words
High-Speed Counter, Pulse-Catch Input, Interrupt Input
