Panasonic FP Series User Manual

Conversion instructions
203
Part II IEC Instructions
DINT_TO_TIME
DOUBLE INTEGER into TIME
To add an enable input and enable output to the instruction, select [With EN/ENO] from the
"Instructions" pane (LD, FBD or IL editor). To reuse an instruction select "Recently used" from the
context menu or press <Ctrl>+<Shift>+<v> in the programming window.
PLC types
Availability of DINT_TO_TIME (see page 1319)
Data type I/O Function
DINT input input data type
TIME output conversion result
Description
DINT_TO_TIME converts a value of the data type DINT into a value of the data type TIME. A value
of 1 corresponds to a time of 10ms, e.g. an input value of 123 is converted to a TIME
T#1s230.00ms.
Data types
Example
In this example, the same POU header is used for all programming languages. For an example
using IL (instruction list), please refer to the online help.
POU header
All input and output variables used for programming this function have been declared in the POU
header.
This example uses variables. You can also use a constant for the input variable.
Body
DINT_value of the data type DOUBLE INTEGER is converted to value of the data type TIME. The
result is written into the output variable time_value.
LD
ST
When programming with structured text, enter the following:
time_value:=DINT_TO_TIME(DINT_value);
