Date and time instructions
296
Part II IEC Instructions
SPLIT_DATE_INT
Split a date into INTEGER values
To add an enable input and enable output to the instruction, select [With EN/ENO] from the
"Instructions" pane (LD, FBD or IL editor). To reuse an instruction select "Recently used" from the
context menu or press <Ctrl>+<Shift>+<v> in the programming window.
Inverse instruction: CONCAT_DATE_INT (see page 283)
PLC types Availability of SPLIT_DATE_INT (see page 1331)
Data type I/O Function
DATE input date
INT
1st output
2nd output
3rd output
year
month
day
SPLIT_DATE_INT(IN := DATE_value,
YEAR => YEAR_value,
MONTH => MONTH_value,
DAY => DAY_value);
Description
SPLIT_DATE_INT splits a value of the data type DATE into INT values for year, month, and day.
Data types
Example
In this example the function has been programmed in ladder diagram (LD) and structured text (ST).
POU header
All input and output variables used for programming this function have been declared in the POU
header.
LD
ST
When programming with structured text, enter the following:
