Panasonic FP Series User Manual

Basics
47
other in LD and FBD. First connect the STRING instructions without EN/ENO and then add an instruction with
EN/ENO in the final position. The enable input (EN) then controls the output of the overall result.

EXAMPLE
This arrangement is not possible:
This arrangement is possible:
Instruction list (IL)
STRING instructions with EN/ENO may be connected to each other in IL. Nevertheless, in order to avoid
intermediate variables, it is recommended that you use a conditional jump instead of connecting a series of
functions with EN/ENO.

EXAMPLE
Program with dummy string
