Chapter 3: FRU Removal and Replacement Procedures
Opening and Closing the Node
78 Quantum DXi6900 G1 User’s Guide
Opening and Closing the Node
WARNING: Opening or removing the system cover when the system
is on may expose you to a risk of electric shock.
Caution: Use appropriate ESD precautions, including the use of a
grounding strap, when working inside the Node.
Some DXi6900 G1 FRU replacement procedures require removing the
Node from the rack and opening the top cover to access the inside of
the Node. Refer to the following sections:
• Opening the DXi6900 G1 Node
• Closing the DXi6900 G1 Node
DXi6900 G1 External Cables
SAS Cable CRU No Yes No
1 GbE Ethernet Cable CRU Yes No No
10 GbE Ethernet Cable CRU Yes No No
SFP+ Module CRU Yes No No
Fibre Channel Cable CRU Yes No No
Power Cable CRU Yes No No
Part FRU or CRU
Hot-Swap
Capable
Shut Down
Required
Service
Menu
Required
