Chapter 3: FRU Removal and Replacement Procedures
Replacing Node CMOS Battery
Quantum DXi6900 G1 User’s Guide 111
• Removing a Failed CMOS Battery from the Node
• Installing a Replacement CMOS Battery in the Node
Identifying a Failed CMOS Battery
To identify a failed CMOS battery in the DXi6900 G1 Node:
1 Log on to the remote management console as the service user (see
Accessing Remote Management on page 25).
2 Navigate to the Status > Hardware > Summary page, and then
click System Board.
The System Board Details window displays.
3 Note if the CMOS battery has a Failed status (see Figure 61).
Figure 61 Checking CMOS
Battery Status.
