Chapter 3: FRU Removal and Replacement Procedures
Replacing Node Memory Modules
Quantum DXi6900 G1 User’s Guide 103
Replacing Node Memory Modules
This section describes how to remove and replace memory modules in
the DXi6900 G1 Node and contains the following sections:
• Obtaining a Replacement Node Memory Module
• Replacing a Node Memory Module
Obtaining a
Replacement Node
Memory Module
Before beginning the replacement procedure, make sure that you have
the required replacement kit. The appropriate replacement memory
module will be provided by Quantum Customer Support (see
Figure 56).
You will need the following items to perform this procedure:
• Replacement memory module kit provided by Quantum Customer
Support.
• ESD grounding wrist strap (included in the replacement kit)
Figure 56 DXi6900 G1 Node
Memory Module
Replacing a Node
Memory Module
This section describes how to remove and replace a memory module in
the DXi6900 G1 Node.
Illustration Description
Replacement memory
module (16 GB DIMM)
PN 12C23
