Appendix A
Cabling Diagrams
Refer to the following diagrams when connecting power, SAS, Ethernet,
or Fibre Channel cables to the DXi6900 G1:
• Figure 147 - DXi6900 G1 SAS Cabling (Node to RBODs)
• Figure 148 - DXi6900 G1 SAS Cabling (RBODs to EBODs)
• Figure 149 - DXi6900 G1 SAS Cabling (EBODs 1-1 through 1-7)
• Figure 150 - DXi6900 G1 SAS Cabling (EBODs 2-1 through 2-6)
• Figure 151 - DXi6900 G1 Power Cabling
• Figure 152 - DXi6900 G1 Fibre Channel Cabling
• Figure 153 - DXi6900 G1 Ethernet Cabling
• Figure 154 - DXi6900 G1 Ethernet Cabling - Optional Quad Port
1 GbE Card
• Figure 155 - DXi6900 G1 Ethernet Cabling - Optional Dual Port
10 GbE Card
