Chapter 3: FRU Removal and Replacement Procedures
Replacing Array or Expansion Module Hard Drives
Quantum DXi6900 G1 User’s Guide 185
Figure 109 Storage Arrays
Page
Note: Qarray1 corresponds with RBOD1 and Qarray2
corresponds to RBOD2
b To view the hard drives within a specific array, click Qarray1 for
the first array and Qarray2 for the second array. The Expansion
modules are listed under the Array modules if present.
The array components page displays (see Figure 110).
