Quantum DXi6900

Chapter 1: Basic Operations
DXi6900 G1 Node
Quantum DXi6900 G1 User’s Guide 9
Table 3 DXi6900 G1 PCI Slot
Configuration Options
Node Hard Drive Carrier
Indicators
Each hard drive carrier has two LED indicators (see Figure 6):
• Drive activity indicator (green)
• Flashing - Indicates hard disk drive activity.
• Drive failure indicator (green and amber)
11 Serial connector Allows you to connect a serial device to the
system.
12 VGA connector
13 USB 2.0 connectors (2)
14 Service port For Quantum use only.
15 3 x 1 GbE Ethernet ports For data ingest/read.
16 Power supply (PSU1) 750 watt hot-swappable power supply.
17 Power supply (PSU2) 750 watt hot-swappable power supply.
Item
Indicator, Button, or
Connector Icon Description
Option PCI Slot 2 PCI Slot 4
101 2 x 10 GbE (SFP+)
Ethernet ports
102 4 x 1 GbE Ethernet ports
103 2 x 10 GBase-T Ethernet port
