Quantum DXi6900

Chapter 3: FRU Removal and Replacement Procedures
Replacing a Node Processor and Heatsink
Quantum DXi6900 G1 User’s Guide 151
Installing a Replacement Network Daughter Card
To install the replacement network daughter card in the DXi6900 G1
Node:
1 Angle the card so that the RJ-45 connectors fit through the slot in
the back panel (see
Figure 91).
2 Align the captive screws at back end of the card with the captive
screw sockets on the system board.
3 Press the touch point on the card until the card connector is firmly
seated on the system board connector.
4 Using a #2 Phillips screwdriver, tighten the two captive screws to
secure the network daughter card to the system board.
5 Replace the quad port SAS card in expansion card riser 2 (see
Replacing an Expansion Card in Riser 2 or 3).
6 Close the Node cover (see Opening and Closing the Node).
7 Turn on the system (see Turning On and Shutting Down the System
on page 23).
8 Run Factory Detect Hardware from the Service Menu to detect the
new hardware (see
Factory Detect Hardware on page 44).
9 In the remote management console, delete any administrative alerts
and close any service tickets.
Replacing a Node Processor and Heatsink
This section describes how to remove and replace a processor (CPU) and
heatsink in the DXi6900 G1 Node and contains the following sections:
• Obtaining a Replacement Processor and Heatsink
• Replacing the Processor and Heatsink
