Quantum DXi6900

Chapter 2: Service Menus
Connecting to the DXi6900 G1 Node
Quantum DXi6900 G1 User’s Guide 33
There are four ways to connect to the Node:
• Connecting to the System Node Using the Service Port
• Connecting to the System Node Using the iDRAC Port
• Connecting to the System Node Using the Serial Port
• Connecting to the System Node Using Santricity
Note: You can also directly connect a monitor and keyboard to the
DXi6900 G1 Node.
Figure 20 Connecting to the
DXi6900 G1 Node (Rear View)
Connecting to the
System Node Using the
Service Port
Connecting to the service port allows access to the root command
prompt and the Service Menu.
To connect to the DXi6900 G1 using the service port:
iDRAC
admin
•Qa@Ip00!
Note: Changes as ServiceLogin password is
changed
Local
User
Default Password
(Access Control)
Account
Enabled/Disabled Access
Service PortSerial PortiDRAC Port
