Chapter 3: FRU Removal and Replacement Procedures
Additional Removal and Replacement Procedures
224 Quantum DXi6900 G1 User’s Guide
Additional Removal and Replacement Procedures
Some FRU procedures require removing and re-installing items in the
Node that are not FRUs themselves. Refer to the following procedures to
remove and re-install non-FRU components in the Node:
• Removing and Installing the Cooling Fan Assembly
• Removing and Installing the PCIe Card Holder
• Removing and Installing the Cable Retention Bracket
• Removing and Installing the Information Tag
Removing and
Installing the Cooling
Fan Assembly
To remove and replace the cooling fan assembly, refer to the following
procedures:
• Removing the Cooling Fan Assembly
• Replacing the Cooling Fan Assembly
Removing the Cooling Fan Assembly
To remove the cooling fan assembly:
1 Unlock the cooling fan assembly from the chassis by rotating the
blue release lever upward (see
Figure 142).
2 Lift the cooling fan assembly out of the chassis.
