Quantum DXi6900

Chapter 1: Basic Operations
DXi6900 G1 Array and Expansion Modules
Quantum DXi6900 G1 User’s Guide 19
Table 6 Array Module LEDs
and Buttons
Button/LED Description
Ethernet link rate
(green)
Solid - port speed 1000MB/sec.
Off - port speed 10/100MB/sec.
Ethernet activity
(green)
Solid - link established.
Blinking - indicates port activity.
SAS host/expansion
fault (amber)
SAS host/expansion
activity (green)
Both Off - cable unplugged.
Fault Off and Activity On - all links
operating.
Fault On and Activity Off - at least one
link active and at least one link fault.
Battery fault (amber) On - battery has failed.
Off - battery operating as normal.
Battery charging
(green)
Blinking - battery is charging.
On - battery is fully charged.
Off - battery fault or no battery.
Service action allowed
(blue)
Solid - safe for Quantum field service. to
remove controller from slot.
Service action required
(amber)
Solid - controller has failed and requires
attention.
Note: Fault light will be on during power
up and will turn off after self-test
sequence completes.
Cache active (green) Solid - unwritten data is stored in cache.
Blinking - during AC power failure, cache
offload is occurring.
Seven segment display
(green)
Displays tray ID and error code. (Displays
99 when the Array module is operating
normally.)
USB Not used.
Mini USB Not used.
Reset switch Not used.
