Chapter 2: Service Menus
Retrieving a Crash Dump File
72 Quantum DXi6900 G1 User’s Guide
Figure 34 Initial WinSCP Log-in
Screen
.
2 Under the Session section of the login screen enter the following
information:
• Hostname - IP Address of the DXi
• Port Number - Leave set to 22
• Username - ServiceLogin
• Password - (see Tab le 8 for system passwords)
Leave all other fields as defaults
Note: You can also leave the Username and Password boxes
blank, and you will be prompted to enter them during the
authentication process.
After you are successfully connected to the DXi system, the default
view will be showing the root directory (see
Figure 35), depending
on the interface that you have selected (Explorer View or Norton
Commander View).
