Chapter 3: FRU Removal and Replacement Procedures
Replacing an Array Module BBU
Quantum DXi6900 G1 User’s Guide 213
Figure 135 Removing and
Installing an Array Module BBU
6 Unscrew the thumbscrew that secures the failed battery to the
controller canister and remove the battery.
Installing a Replacement Array Module BBU
To install the replacement Array module BBU:
1 Insert the new battery by sliding it towards the front of the
controller canister (see
Figure 135).
Cover release buttons
Battery
Thumbscrew
