Chapter 3: FRU Removal and Replacement Procedures
Replacing a Node Processor and Heatsink
Quantum DXi6900 G1 User’s Guide 153
Replacing the Processor
and Heatsink
This section describes how to remove and replace a processor and
heatsink in the DXi6900 G1 Node.
Caution: Use appropriate ESD precautions, including the use of a
grounding strap, when performing this procedure.
Removing and replacing the processor and heatsink in the Node
includes the following steps:
• Identifying a Failed Processor and Heatsink
• Removing a Failed Processor and Heatsink
• Installing a Replacement Processor and Heatsink
Identifying a Failed Processor and Heatsink
The DXi6900 G1 Node contains two processors (CPUs), and each is
covered by a heatsink to dissipate heat.
To identify a failed processor and heatsink:
1 Access the remote management console (see Accessing Remote
Management on page 25).
2 Navigate to the Status > Hardware > Details > System Board
page.
3 Note the status of CPU1 and CPU2 (see Figure 93).
