Quantum DXi6900

Chapter 1: Basic Operations
Turning On and Shutting Down the System
24 Quantum DXi6900 G1 User’s Guide
Figure 14 Powering on the
DXi6900 G1 Expansion
Modules (EBODs)
Figure 15 Powering on the
DXi6900 G1 Array Modules
(RBODs)
Figure 16 Powering on the
DXi6900 G1 Node
ID/Diag
Port 1
ID/Diag
Port 1
Power switches
Expansion module (rear view)
Seven segment display
Port 1
Port 2
ID/
Diag
|O|O|
Port 1 Port 2
ID/
Diag
|O|O|
Power switches
Array module (rear view)
Seven segment display
Power button
Node (front view)
