Quantum DXi6900

Appendix A: Cabling Diagrams
Quantum DXi6900 G1 User’s Guide 247
Figure 154 DXi6900 G1
Ethernet Cabling - Optional
Quad Port 1
GbE Card
Figure 155 DXi6900 G1
Ethernet Cabling - Optional
Dual Port 10 GbE Card
System Node (Rear)
To 1 GbE Network
System Node (Rear)
To 10 GbE Network
