Figure 13 Expansion Module
LED Indicators – Rear Panel
Lnk Lnk
ID/Diag
Port 1
ID/Diag
Port 1
Standby power
Service action allowed
DC enabled Service action required
AC enabled
Power switch
SAS expansion activity
SAS expansion fault
Serial port
Ethernet link rate
Ethernet activity
SAS host 2 activity
SAS host 2 fault
SAS host 1 activity
SAS host 1 fault
Seven segment display
Power
Service action required
Service action allowed
