Chapter 3: FRU Removal and Replacement Procedures
Replacing Node Memory Modules
106 Quantum DXi6900 G1 User’s Guide
Figure 57 DXi6900 G1 Node
Memory Module Locations
White sockets - 8 memory modules are installed for all configurations
Black sockets - 8 memory modules are installed for 119 TB and larger configurations
Green sockets - Not used
