Chapter 3: FRU Removal and Replacement Procedures
Replacing Node Memory Modules
Quantum DXi6900 G1 User’s Guide 105
119–510 TB
1 or 2 RBODs
3 or more EBODs
256 GB • 8 memory modules are
installed in slots A1–A4 and
B1–B4 (
white sockets).
• 8 memory modules are
installed in slots A5–A8 and
B5–B8 (
black sockets).
DXi6900 G1
Configuration
Total System
Memory Installed Memory Modules
