Chapter 1: Basic Operations
DXi6900 G1 Node
4 Quantum DXi6900 G1 User’s Guide
Node Front Panel
Features and Indicators
Figure 4 shows the controls, indicators, and connectors located behind
the optional rack bezel on the front panel of the Node. Tab le 1 describes
each item.
Figure 4 DXi6900 G1 Node
Front View
1 2 3 4 5 6 7
8 9 10
