Quantum DXi6900

Chapter 3: FRU Removal and Replacement Procedures
Replacing Node Hard Drives
Quantum DXi6900 G1 User’s Guide 91
Use the indicator LEDs on the hard drive carrier to identify the failed
hard drive (see
Figure 47):
• Drive activity indicator (green)
• Flashing - Indicates hard disk drive activity.
• Drive status indicator (green and amber)
• Off - Drive ready for insertion or removal
Note: The drive status indicator remains off until all hard
drives are initialized after system power is applied.
Drives are not ready for insertion or removal during this
time.
• Blinks green two times per second - Identify drive/preparing
for removal
• Blinks green, amber, and off - Drive predicted failure
• Blinks amber four times per second - Drive failed
• Blinks green slowly - Drive rebuilding
• Steady green - Drive online
• Blinks green three seconds, amber three seconds, and off
three seconds - Rebuild aborted
Note: If a drive fails, you will be notified by a service ticket in the
remote management console.
Caution: All drives are hot swappable. When replacing drives, never
remove more than one drive at a time from a RAID set.
After removing a drive, first wait one minute. Then insert a
working drive and wait for the RAID set to finish rebuilding
(red indicator light is off) before removing another drive.
