Chapter 3: FRU Removal and Replacement Procedures
Replacing the Node Chassis
Quantum DXi6900 G1 User’s Guide 181
Caution: Take care not to damage the system identification
button while placing the system board into the chassis.
3 Push the system board toward the back of the chassis until the
board clicks into place.
4 Install the following components (removed form the failed Node
chassis) in the replacement Node chassis:
a Hard drive backplane (see Replacing the Hard Drive Backplane
on page 160).
b Information tag (see Removing and Installing the Information
Tag on page 228).
c Cable retention bracket (see Removing and Installing the Cable
Retention Bracket on page 227).
d PCIe card holder (see Removing and Installing the PCIe Card
Holder on page 226).
e Integrated storage controller card (see Replacing the Integrated
Storage Controller on page 136).
f Expansion card risers (see Replacing an Expansion Card in Riser
1 on page 118 and Replacing an Expansion Card in Riser 2 or 3
on page 122).
g Cooling fan assembly (see Removing and Installing the Cooling
Fan Assembly on page 224).
h Power supplies (see Replacing a Node Power Supply on
page 95).
5 Reconnect all cables to the system board.
Note: If using optical 10 GbE cables, move the SFPs from the
failed Node chassis to the replacement Node chassis.
Note: Ensure that the cables inside the system are routed along
the chassis wall and secured using the cable securing
bracket.
6 Close the Node cover (see Opening and Closing the Node).
