RADWIN2000UserManual Release2.8.30 7‐9
StatusBar
TheStatusbar,displaysthefollowingicons:
RADWINRNMSuserswillseeanadditionalfieldshowingtheIPaddressoftheRNMSserver:
Table7‐3:Statusbarindicators
IconorLabel Purpose
Connectivity
ShowsifRADWINManageriscommunicatingwiththeODU.
Connection
available
ConnectionmodetotheODU
•Over‐the‐Airconnection‐usingtheIPaddressofthe
remoteunit.
•Localconnection‐directconnectiontotheIDUwithout
usinganIPaddress.
•Networkconnection‐throughaLAN
ODUunreachable
IPAddress
LogonIPaddress
Encryption
indicator
Normallyencryptedlink
Linkpasswordvalidationfailed.Thelinkisencryptedwith
defaultkeys.
Serviceandconfigurationareunavailable.Changethelink
password.
LinkLock
LinkLockenabled
LinkLockencrypted
LinkLockmismatch
EthernetRing
Member
DFSinuse
RescueAlarm
Intheeventofanactivealarm,opensalarmsdialog
