RADWIN2000UserManual Release2.8.30 4‐16

InstallingaLink

Figure4‐23:Attachingthemountingkittothepole

Figure4‐24:Mountingkitinplaceonthepole

7 WasherspringM8 3

8 M8Nuts 2

Table4‐1:BillofMaterials:Standardmountingkit(Continued)

Item

No.

Description

Quantit
