RADWIN2000UserManual Release2.8.30 14‐4
GSUKitContents
IfthePrimaryGSUfails,andthentheSecondaryGSUalsofailstoreceivesyncsignalsfromits
GPS,thenitmovestoself‐generationHSMmodelikeanordinaryHSMODUuntilitsGPS
recovers.
Figure14‐4:MaketheGSUsthefirsttwocollocatedunits
RedundancyswitchingiscompletelytransparenttotheGSU‐managedlinks.
GSUKitContents
TheGSUpackageincludes:
• 1xGSU
• 1xMountingKit
• 1xGPSAntenna
• 1xGPSAntennaMountingKit
• 1xRFCable,1.5m
• CD
