IDU‐Haggregationunit
IDU‐Haggregationunit
TheIDU‐HprovidesaggregationformultipleRADWINODUsatahubsite.Itsupportsall
RADWINODUs.Itfeatures‐
• SixPoEports(PoElegacymode/RADWINPoE)
• Upto25WperPoEport
• 2LANInterfaces10/100/1000Mbps;auto‐negotiation
• SFPInterfaces:2xSFPportsof1000Mbps(standardMSA)
Itis19”rackmounted,1Uandhalfwidth.Powerfeedingis44VDC‐56VDC,Dualredundant
inputsthroughstandardIDU‐Ctypeadapters.
Figure4‐9:IDU‐Hfrontpanel
TheIDU‐Hpackagecontains:
• OneIDU‐H
• Oneshortmountingear
• Onelongmountingear
• Onedualconnectortojointwounitsmountedsidebyside
• TwoDCpowerplugsforpowercables‐seeFigure4‐10below
Figure4‐10:DCthreepinpowerplug
Thepowerconnectorsare3pininlinefemale,withpolarities(lefttoright)minus,ground,
plus.Ifrequired,anAC/DCpoweradaptershouldbeorderedseparately,dependingonyour
region.
TheIDU‐Hmaybeinstalledinsingleordoubleconfigurations:
