RADWIN2000UserManual Release2.8.30 27‐12

RunningtheLinkBudgetCalculator

Figure27‐13:WorldmapshowingCFactorcontours

9.Atanytime,clickCalculatetorecalculatetherequiredperformanceestimate.

Figure27‐14:LBC‐Resultssection

TheExpectedPerformanceparametersarecalculatedanddisplayed:

•ExpectedRSS‐theexpectedRSSthattheRADWINManagershowswhentheRADWIN

2000ODUsareoptimally aligned

Note

Placingthecursorinanyothercalculatedfieldwi ll alsoupdatethe

calculatedresults.
