RADWIN2000UserManual Release2.8.30 4‐2
What’sinthebox
• Establishingaradiolink
What’sinthebox
UnpackingandChecking
 Foreachoftheitemsbelow,dothefollowing:
1.Removetheequipmentfromthebox.
2.CheckthateverythinglistedontheincludedBillofMaterialsorPro‐formaInvoiceis
present.
3.Ifanyitemismissing,contactCustomerService.Youwillbeadvisedwhetherto
returnthepackageforreplacement,orwhetherthemissingitemcanbesupplied
separately.
4.Donotdisposeofthepackaginguntiltheunitisinstalledandoperational.
ODURadios
ARADWIN2000ODUpackageincludesthefollowingitems:
• OneODU‐seethenextfigureforfrontandrearview
Figure4‐1:StandardODUFormFactors‐AllseriesotherthanAandB
Front Rear
ConnectorizedIntegratedAntenna
