Radwin 2000 User Manual

RADWIN2000UserManual Release2.8.30 15‐3
PurposeofthisChapter
PurposeofthisChapter
ThischapterisaninstallationandmaintenanceguideforRADWINMHS.Itappliestoall
RADWINradioproductsabletosupporttheMonitoredHotStandbyoperationalmode.
WhoShouldReadthis
Thischapterisintendedforpersonsresponsiblefortheinstallationandmaintenanceof
RADWINMHS.Touseityouneedtoknowhowto‐
• InstallaRADWIN2000radiolink
• UsetheRADWINManagersoftware
RADWINMHSKitContents
• OneY‐ConnectionPatchPanel
• OneMHScable
Figure15‐2:RADWINY‐ConnectionPatchPanel
InstallingaRADWINMHS
Figure15‐1aboveisaschematic ofaRADWINMHS.Figure15‐3showshowtoconnectthe
IDUstothePatchPanel.
Note
Thefo llowingprocedureissubstantiallygenerictoallRADWINradio
products.WhatyouseeonyourrunningRADWINManagermaydifferin
somedetailsfromthescreencapturesusedtoillustratethischapter.
