SettingupQoS
Figure21‐3:Top:VLANallocation.Bottom:Diffservallocation
4.Theentryfieldsinbothcasesareselfevident.UponclickingOK,
• Ifyouover ‐booktheWeightcolumn,thelastenteredfieldwillbereducedsothat
thetotalis100%.
• Noweightfieldmaybeleftzero.Ifyoudo,youwillnotbeabletoproceeduntilitis
settosomething:
Thisreflectstheimplementationpolicyunderwhichnocheckedqueuemaybe
complete lystarved.Ifyoureallydonotwanttouseaqueueundercongestion,
uncheckit.
• Ifyouareunder‐booked,youwi ll receivethisnotice:
• Inanyevent,youmayautomaticallyapplythesamesettingstobothlinksites:
