RADWIN2000UserManual Release2.8.30 9‐38

TDMMHSStatus

Thesync‐lossthresholdvalue,whichyouenterisabsolute .sync‐losswillonlyoccurif

throughputfallsbelowit.

TDMMHSStatus

HereyoucanseetheTDMMHSstatus.Thereisnothingtoset.

Note

• Thedefaultvalueisdeterminedbyanalgo rithmtakingintoaccount

yourcurrentlinkradioparameters

• Thereisaprovisiontooverrideanexcessivelyhighvaluethatwould

leadtocontinuoussync‐loss“thrashing”:Anexcessivelyhighvalue

willbeignoredbythesystem.

• Anexcessivelylowvaluemaypreventsync‐losseventsalmostentirely,

inturnpreventingtheACSmechanismfromworkingeffectively.
