RADWIN2000UserManual Release2.8.30 10‐2
RetrievingLinkInformation(GetDiagnostics)
Thefollowingtablelistslinkandsysteminformationthatcanbemonitored.
 Togetdiagnostics
1.FromtheHelpmenu,chooseGetDiagnosticsInformation.
Figure10‐1:GetDiagnosticsDialogBox
2.Selectordeselectthedataoptions.IfthefileistobesenttoRADWINCustomer
Supportleavealloptionschecked.
3.ClickFilePathtospecifythefolderinwhichyouwanttosavethefileandthenclick
Starttosavetheinformat ion.
Table10‐1:GetDiagnosticsDataandDescription
Data Description
SystemData Generalinformationaboutthesystem
LinkInformation Informationaboutthelinkproperties
EventsLog
•Listofsystemeventsincludingthosefromother
sitesifthissiteisdefinedasthetrapdestination
•Last256eventsfrombothsites
SiteConfiguration Dataaboutthesiteparameters
ActiveAlarms Listofactivealarms
Performance Networkperformancedataoverdefinedtimeperiods
Monitor Detailedeventdatarecord
SpectrumView DatafromlastSpectrumViewrun
