Radwin 2000 User Manual

RADWIN2000UserManual Release2.8.30 4‐17
InstallingaLink

Thepurposeofthearm(Figure4‐22),istoenablesingle‐poleantennas(deprecated)tobe
rotatedthrough90°forcorrectverticalalignmentorsimplytodistancetheantennaorODU
fromthepole.
GroundingtheODU
ThereisagroundinglugontherearoftheODUasshowninFigure4‐27.Connectittoground
using10AWGwire.Groundingisoftencarriedoutinconjunctionwithlightningprotection.
Figure4‐27:ODU:Groundinglug
MountingaSmallFormFactorODU
AsmallformfactorODUmountingkithasamountingkitadapterandtwometalties:
Figure4‐25:MountedconnectorizedODU Figure4‐26:MountedODU:Integratedantenna
