RADWIN2000UserManual Release2.8.30 4‐19
InstallingaLink
Figure4‐30:Securingthemountingadapter
2.ReferringtoFigure4‐31below:AttachtheODUmountingkit(1)tothemounting
adapterear(4)andproceedasabove,forastandardODU.
Figure4‐31:Attachingastandardmountingkit
InstallingaPoEdevice
ThePoEdevice(Figure4‐7)isaverysimplepieceofequipment.IthasarecessedthreepinAC
powerplug,amatchingpowercable,aLAN‐Inport(fromaswitch),aLAN‐Outport(tothe
ODU)andapowerLED,greenundernormaloperation.Itistypicallystrappedintoanetwork
equipmentrackusingplasticties.Itmayalsositfreeonatrayortable‐top.
Note
• WhenmountinganODUonapoleorwall,ensurethattheunitisori‐
entedsothatthecableconnectorsareatthebottom.
• DonotmountanODUhorizontally
• ForanODUwithanintegratedantenna:DonottightentheODUtoits
mountingbracketuntiltheantennaalignmentprocessiscomplete.
• EnsurethattherearenodirectobstructionsinfrontoftheODUor
interferencefromman‐madeobstacles.
