RADWIN2000UserManual Release2.8.30 11‐8
HSSErrorNotification
HSSErrorNotification
IntheeventofanHSSinstallationfault,theODUwillsoundabeeppatternaccordingtothe
followingchart,alsoprintedontheODUproductlabel:
Figure11‐7:ODUbeepforHSSError
Forthispurpose,ODUbuzzermustbesettoAutoorOn.
Orange
HSSisoperational.Oneofthefollowingconditionsapply:
•ThisODUisamasterthatisgeneratingsignalsanddetectingsignals
•ThisODUisamasterthatisgeneratingsignalsbutdetectedimpropersig‐
nals
•ThisODUisaclient“ContinueTx”butisnotdetectingsignals
•ThisODUisaclient“DisableTx”andisdetectingsignalsfrommultiple
sources
Allorangecasestransmit.
Off
HSSisnotactivated
HSSisnotsupported(WinLink1000only)
DisconnectionbetweenODUandIDU
Table11‐5:IDU‐CandIDU‐EFrontPanelLEDsforHSS(Continued)
Color Function
