Radwin 2000 - Figure 8-9 Antenna Configuration

To Next Page

To Previous Page

RADWIN2000UserManual Release2.8.30 8‐11

Configuration

Figure8‐9:Antennaconfigurationdialogwithopenedtypeselection

(RecallthatweareusinganunrealisticallylowTxpowerher ebecauseourlinkina

laboratory.)

Sofar,theprocedureduplicatesthecorrespondingInstallationprocess.Ifyouchoosea

differentantennatypeandclickOK,youwillreceivethefollowingcautionarymessage:

Caution

Inthiscontext,enteringInstallationmodecausesaservicebreakuntilitis

restoredbyrunningtheInstallationwizard.

Ifyouareuncertain,donotdothiswithoutexperttechnicalassistance.
