RADWIN2000UserManual Release2.8.30 9‐2

EditingtheConfigurationParametersbySite



Figure9‐1:ConfigurationDialogBox

Functionsontheleftofthedialogbox:

Table9‐1:SiteConfigurationtabs

Tab Purpose

System Editthecontactpersonandlocationdetails.Viewthesystemdetails

AirInterface ChangetheTxPower,cableloss,antennatypeandsettings.

ViewHSSsettings

Management ConfiguretheIPaddress,SubnetMask,DefaultGateway,Trap

DestinationandVLAN

Inventory Viewthehardwareandsoftwareinventory(productidentification,

versions,MACaddressandserialnumber)

Security ChangetheCommunityValuesandtheLinkPassword.SetLinkLock.
