RADWIN2000UserManual Release2.8.30 A‐17
AntennaCharacteristics
Mechanical
Environmental
Safety
EMC
AntennaCharacteristics
Anantennaistheradiatingandreceivingelementfromwhichtheradiosignal,intheformof
RFpower,isradiatedtoitssurroundingsandviceversa.Thetransmissionrangeisafunction
oftheantennagainandtransmittingpower.Thesefactorsarelimitedbycountryregulations.
TheRADWIN2000maybeoperatedwithanintegratedantennaattachedtotheODUunit,or
withanexternalantennawiredtotheODUviaN‐typeconnectors.Allcablesandconnections
mustbeconnectedcorrectlytoreducelosses.Therequiredantennaimpedanceis50Ω.

Connectiontype
RJ45CAT5eSTP(shielded)
Pin-out
8wires+shielding
Enclosure
Metal
ConnectiontobondingNetwork
Screw
Dimensions
150mm
Weight
220gram(0.22Kg)
Operatingtemperature
‐40°Cto60°C
Storagetemperature
‐50°Cto70°C
Enclosurerating
IP67
Humidity
100%noncondensing
TUV
UL60950‐1,UL60950‐22,CAN/CSAC22.260950‐1,CAN/
CSAC22.260950‐22
ETSI/IEC
EN/IEC60950‐1,EN/IEC60950‐22
FCC
CFR47ClassB,Part15,SubpartB
ETSI
EN300386,EN301489‐4,EN301489‐1
CAN/CSA‐AS/NZS
CISPR22ClassB
