RADWIN2000UserManual Release2.8.30 B‐2
UserPortConnectors
UserPortConnectors
LANPort
TheLAN10/100BaseTinterfaceterminatesinan8‐pinRJ‐45connector,wiredinaccordance
toTableB‐3.
TrunkPorts‐E1/T1RJ45Connector
TheE1/T1interfacesterminatein8‐pinRJ‐45connectors,asshowninTableB‐4below:
HotStandbyPortRJ‐11
White/Blue 5 5
White/Brown 7 7
Brown 8 8
TableB‐3:Fast Ethernet Connector Pinout
Function Signal Pin
TransmitData(positive) TD(+) 1
TransmitData(negative) TD(–) 2
ReceiveData(positive) RD(+) 3
ReceiveData(negative) RD(–) 6
TableB‐4:Trunk Ports - E1/T1 RJ45Pinout
Function Signal Pin
TransmitDataTip TxTip 1
TransmitDataRing TxRing 2
ReceiveDataTip RxTip 4
ReceiveDataRing RxRing 5
TableB‐5:Hot Standby RJ-11 Port Pinout
Signal
Pin
SideA
Pin
SideB
HSBout 1 2
HSBin 2 1
TableB‐2:ODU/HSS Unit Connection Pinout (Continued)
Color
ODU
RJ‐45
HSSUNIT
RJ‐45
